Lithium Ion solar battery 51.2v 100ah 200ah 300ah

2024-08-27 11:02

Описание товара

Номинальное напряжение	51,2 В	51,2 В	51,2 В
Номинальная мощность	100Ач	230Ah	304AH
энергии	5120Втч	11776Wh	15360wh
Series or Parallel Connection	16С1П	16С1П	16С1П
Максимальный ток заряда	100А	200А	200А
Charge Current (-20 to - 10 ºC)	≤0.05C	≤0.05C	≤0.05C
Рекомендуемое напряжение заряда	56V-57.6V	56V-57.6V	56V-57.6V
Отключение напряжения заряда BMS	57.6V (3.75±0.025vpc)	57.6V (3.75±0.025vpc)	57.6V (3.75±0.025vpc)
Повторно подключить напряжение	54.6V (3.34 ±0.05vpc)	54.6V (3.34 ±0.05vpc)	54.6V (3.34 ±0.05vpC)
Dimensions (L x W x H)	440*435*222mm (17.3x17.1x8.74”)	480*248*618mm	475*255*770mm
вес	70KG with wooden packing	:116KG with wooden packing	138KG with wooden packing
Коммуникационный интерфейс	RS485 (Optional)	RS485 (Optional)	RS485/CAN (Optional)
Материал корпуса	Металл	Металл	Металл
Enclosure Protection	IP54	IP54	IP54
Максимальный непрерывный ток разряда	100А	200А	200А
Отключение тока разряда BMS	105А	230А	230А
Повторно подключить напряжение	45V	45V	45V
Температура разряда	-20 to 60ºC (-4 to 140 ºF)	-20 to 60ºC (-4 to 140 ºF)	-20 to 60ºC (-4 to 140 ºF)
Температура заряда	0 to 45ºC (32 to 113 ºF)	0 to 45ºC (32 to 113 ºF)	0 to 45ºC (32 to 113 ºF)

* Please Click Here:We Provide OEM /ODM Service !
* Quick Delivery From China.
Мы стремимся производить самые безопасные литий-железо-фосфатные батареи.
Все наши батареи прошли строгие испытания и сертифицированы как безопасные для использования по всему миру.
Все литиевые батареи в наших продажах соответствуют CE, UN38.3, MSDS и другим правилам транспортировки, быстрая доставка с места!
Если вам нужен сертификат, связанный с продуктом, пожалуйста, свяжитесь с нами, чтобы отправить вам!
* For additional benefits For resellers

we provide super price for you and policy, We offer one-stop solar energy storage solutions,please contact us directly and we will tell you more. Most importantly, we can provide you with professional solutions tailored to your local market.



Products Feature

1.Excellent safety performance: Safest lithium iron phosphate battery, CE BIS, MSDS, UN38.3 approved, with built-in BMS.

2.Long cycle life and deep cycle: Performs more than 6000 cycles, 6-8 times longer than lead acid battery.

3.No memory effect, highly efficient and high energy density.

4.Compact size and light weight: 1/2 size & weight of lead acid battery

5.Excellent high temperature performance

6.Low self-discharge rate: < 3% per month

7.High IP standard: IP65 Waterproof.



заявка

Наш завод



Доставка и упаковка

Вопросы-Ответы

Q1. Do you have MOQ (Minimum Order Quantity) limit?
A: No, ALL IN ONE do not have MOQ limit, 1pc sample order or small quantity is available.

Q2. Как насчет времени выполнения заказа?
A: Standard product lead time: Samples: 3-5 days, Bulk order: 3-4 weeks.
Customized product lead time: 3-4 weeks both for sample or bulk order.

Q3. How do you ship the goods? How about the Shipping time?
A: By air door to door (6-12 days): FEDEX, UPS or DHL, suitable for urgent small order.
By sea door to door (25-50 days): suitable for bulk order.
By sea to delivery port (20-35 days): Suitable for bulk order.
By Air to airport (3-5 days): Suitable for urgent heavy package.

Q4. How to proceed with an order?
A: Firstly, providing your requirements or applications, then we will provide battery solution and quote accordingly.
Secondly, confirming the order and do the deposit for it, then we will arrange the production.

Q5. Is it available to print my logo on the product?
A: Yes. For OEM Demand please send us your logo and we will make a label for the product. For product with metal/aluminum case, logo silk-print on the case is available.
